Overview

The SH-300 is an advanced automatic wrapping machine featuring a rotating arm mechanism. It is engineered to deliver high performance and reliability in various industrial packaging applications. This machine ensures that packaged goods are securely wrapped, preserving their integrity during transit and storage. Its automated functions minimize manual intervention, boosting operational efficiency.

Key Features

The SH-3-00 is equipped with several automated features designed for seamless operation:

• Automatic Film Handling: Includes integrated units for gripping, cutting, and welding the stretch film.
• Precision Control: The speed of the reel holder's ascent and descent, arm rotation speed, and acceleration/deceleration are precisely managed by an inverter system.
• Enhanced Safety: Comes standard with safety fences featuring interconnected access doors and limit switches to ensure operator safety.

Technical Specifications

Detailed technical data for the SH-300 machine is provided below:

Specification	Value
Standard Transport Line Height	500 mm
Maximum Arm Rotation Speed	36 rpm
Total Installed Power	4 kW
Power Supply Voltage	400 V - 3f + N + PE
Electric and Motor Protection	IP54
Operating Pressure	6 bar
Maximum Pallet Diagonal	1700 mm
Mechanical Pre-stretch	150% up to 300%
Suitable Film Type	12 to 30 micron stretch film (micro-perforated film also suitable)
Air Consumption	10 Nl/cycle

Optional Features

To further customize the machine's capabilities, the following options are available:

• Motor-powered pre-stretch
• Top sheet application device
• Device for film height reduction

Benefits of Using the SH-300

Choosing the SH-300 automatic rotating arm wrapper brings several advantages:

• Optimal Protection: Provides effective sealing against water, damp, and dust, crucial for sensitive goods.
• High Flexibility: Adaptable to various package sizes thanks to the rotating arm design.
• Increased Throughput: Automated operations accelerate the wrapping process compared to manual methods.
• Consistent Results: Ensures uniform and secure wrapping for every pallet or package.
• Improved Safety: Built-in safety features protect personnel during operation.

Applications

The SH-300 automatic wrapping machine is suitable for a wide range of industries requiring reliable pallet wrapping, including:

• Glass
• Food & Beverage
• Paper & Cardboard
• Wood
• Building Materials
• Steel Industry
• And more...

The SH-300 is a robust and flexible solution for automating your end-of-line packaging process, ensuring your products are protected and prepared for distribution.
