Introduction to the SH-L5ST Automatic Strapping Machine
The SH-L5ST automatic vertical strapping machine is engineered to streamline the packaging process for a wide range of industrial products. Featuring a strapping head positioned laterally relative to the product's direction of movement, this machine automates the application of one or multiple vertical straps.
While highly versatile for any industrial application and product dimension, the SH-L5ST was specifically developed with the demanding requirements of the shingle and tiles sector in mind.
Robust Construction and Design
The machine is built upon a foundation of strong carpentry, forming the core structure of the strapping unit. Its construction utilizes modern technologies and is assembled from precisely dimensioned, electro-welded sheet steels.
Key construction features:
- Material: All-steel construction.
- Protection: Painted and/or protected with appropriate surface treatments to ensure durability in various environmental conditions.
- Adaptability: Designed to accommodate different formats and types of products based on customer needs.
This robust design guarantees reliability and a long operational life even under challenging industrial conditions.
Flexibility and Maintenance
Like other automatic strapping machines from SHJLPACK, the SH-L5ST can be significantly personalized. Numerous optional devices are available to tailor the machine's functionality to specific production requirements.
Ease of maintenance is a core design principle. The machine's logical construction facilitates simple and straightforward maintenance procedures, minimizing downtime.
For applications in the tiles sector, the SH-L5ST is equipped with a manual vertical regulation system. This allows the strapping head height to be easily adjusted, optimizing performance for varying product heights.
Technical Specifications
The SH-L5ST delivers reliable performance with the following technical specifications:
| Feature | Specification |
|---|---|
| Type of Strap: | Polypropylene (PP) and Polyester (PET) |
| Suitable Strap: | Width: 8 to 19 mm |
| Thickness: 0.50 to 1.00 mm | |
| Strap Tensioning: | Up to 300 kg |
| Strap Junction: | By welding or vibration |
| Strapping Cycle Time: | From 1.2 to 3 seconds (depending on tensioning) |
| Power Supply: | 400 V 50Hz |
| Installed Power: | 0.85 kW |
| Arch Size: | Standard: 1200 x 1400 mm |
| Tailored arches available on request |
